Antal Cam 814 Clutch 10/12 Double

V-Cam 814, double clutch, for lines Ø10-12

Technical Description Features Metric American Length (L) 6.08 in 154.5 mm Width (W) 2.56 in 65 mm Height (H) 3.07 in 78 mm min line 0.39 in 10 mm max line 0.47 in 12 mm A 1.42 in 36 mm B 4.13 in 105 mm C 0.53 in 13.5 mm E 1.14 in 29 mm Type – Double Fixing screws 0.16 x 0.31 in 4 x Ø8 mm MWL 2645.55 lb 1200 kg Weight 2.43 lb 1100 g
