Antal Cam 814 Clutch 10/12 Quadruple

V-Cam 814, Quadruple clutch, for lines Ø10-12

Technical Description Features Metric American Length (L) 6.08 in 154.5 mm Width (W) 4.84 in 123 mm Height (H) 3.07 in 78 mm min line 0.39 in 10 mm max line 0.47 in 12 mm A 1.42 in 36 mm B 4.13 in 105 mm C 0.53 in 13.5 mm E 1.14 in 29 mm Type – Quadruple Fixing screws 0.31 x 0.31 in 8 x Ø8 mm MWL 2645.55 lb 1200 kg Weight 4.63 lb 2100 g
