Description
Harken 100mm Aluminum Swivel Block
Sideplates are constructed of hardcoat-anodized 6061-T6 aluminum for strength and corrosion resistance. The ultralight composite bearing system (ULC) rides on a heat-treated stainless steel inner race to handle extremely high loads.
Technical Description
| Sheave Ø (mm) | 100 mm |
| Sheave Ø (in) | 3 15/16 in |
| Length (mm) | 222 mm |
| Length (in) | 8 3/4 in |
| Weight (kg) | 1.2 kg |
| Weight (lb) | 2.65 lb |
| Maximum line Ø (mm) | 16 mm |
| Maximum line Ø (in) | 5/8 in |
| Maximum working load (kg) | 5000 kg |
| Maximum working load (lb) | 11025 lb |
| Breaking load (kg) | 10000 kg |
| Breaking load (lb) | 22050 lb |
