Description
Harken 175mm Aluminum Swivel Block
Sideplates are constructed of hardcoat-anodized 6061-T6 aluminum for strength and corrosion resistance. The ultralight composite bearing system (ULC) rides on a heat-treated stainless steel inner race to handle extremely high loads.
Technical Description
| Sheave Ø (mm) | 175 mm |
| Sheave Ø (in) | 6 7/8 in |
| Length (mm) | 414 mm |
| Length (in) | 16 5/16 in |
| Weight (kg) | 6.05 kg |
| Weight (lb) | 13.34 lb |
| Maximum line Ø (mm) | 25 mm |
| Maximum line Ø (in) | 1 in |
| Maximum working load (kg) | 12800 kg |
| Maximum working load (lb) | 28225 lb |
| Breaking load (kg) | 25600 kg |
| Breaking load (lb) | 56450 lb |
