Description

Specifications:

• Vessel Length: 32′-42′ (10-13 m)
• Voltage: 12 VDC
• Motor Wattage: 1000 Watt
• Max Load: 1100 lb (500 kg)
• Work Load: 275 lb (125 kg)
• Amps Work Load: 100
• Max Line Speed: 48’/min (14.5 m/min)
• Chain Sizes: 5/16 BBB or HT, 3/8 BBB or HT
• Rope Sizes: 1/2, 9/16, 5/8″
• Finish: 316 Stainless Steel

Features:

• Polished stainless steel components
• Rope chain combination gypsy for rope and chain combination or chain only
• Rope Chain Management System (RCMS)
• Quick release integrated swivel chain pipe cover
• Gypsy with low profile clutch top arrangement
• Heavy duty marine grade, dual direction motor in 12V and 24V DC, Hydraulic
• Independent gypsy and capstan operation
• Capstan model features heavy duty knurled finish for increased grip
• Quick fit adaptor
• Stainless steel shaft
• Cone clutch/brake
• Stainless steel mounting bolts
• Shaft seal
• Self lubricating bush
• Clutch release handle
• Made with premium materials
• High-grade design delivers extended lifespan
