Description

Features:

• Dual Direction, Permanent Magnet Motor
• Stainless Worm Drive, Self-Aligning Radially Adjustable Gearbox
• 316 Stainless Steel Finish
• Bronze Gears
• Stainless Mainshaft
• Swiveling Chainpipe
• Chrome Chain Stripper with Stainless Steel Band
• Stainless Steel Studs, Washers, and Nuts
• Ideals for boats ranging from 38′ – 48′ (12-15m)

Specifications:

• Version: Low Profile
• Vessel Length: 38-48 ft (12-15m)
• Voltage: 12VDC
• Motor Wattage: 1200W
• Max Load: 2200 lb (1000 kg)
• Work Load: 550 lb (250 kg)
• Amps Work Load: 120
• Max Line Speed: 50 ft/min (15 m/min)
• Chain Sizes: 1/4BBB or HT 5/16BBB or HT 3/8BBB or HT
• Rope Sizes: 1/2 9/16 5/8 in.
• Finish: 316 Stainless Steel
• Weight: 61.000 lbs
