Description

Features:

• Dual Direction, Permanent Magnet Motor
• Stainless Worm Drive, Self-Aligning Radially Adjustable Gearbox
• 316 Stainless Steel Finish
• Bronze Gears
• Stainless Mainshaft
• Swiveling Chainpipe
• Chrome Chain Stripper with Stainless Steel Band
• Stainless Steel Studs, Washers, and Nuts
• Ideals for boats ranging from 58′ – 83′ (18-26m)

Specifications :

• 24V Low Profile Design
• 2000W Motor
• Power Rating 4000lbs
• Approximately 70 Amps Draw
• Approximately 70 Amps Work Load
• Max Load 4000lbs (1818kg)
• Work Load 1000lbs (454kg)
• Max Retrieval Speed at 44ft/min.
• 5/16BBB or HT, 3/8BBB or HT, 1/2HT
• 9/16, 5/8, 3/4 in.
• Net weight 101lbs
• Max 60mm deck clearance (extra deck clearance available up to 6″)
