Description

Manufacturer part #: TY1050-CR

	Features	American	Metric
A	1.94 in	49.5 mm
B	2.26 in	57.4 mm
C	11.33 in	288 mm
Weight	8.73 lb	3.9 kg
Working Load	25000 lb	11340 kg
Breaking Load	50000 lb	22680 kg

Recommended Applications: 100′ Maxi Boats.
Manufacturer part #: TY1050-CR
Tylaska T50 Snap Shackles are the largest trigger-type snap shackle ever made. They can be opened using either a trigger or lanyard. A lanyard allows for remote operation – ideal for towing applications. The locking pin provides extra security T50from accidental release.
SB – Standard Bails
Provide ample room for attaching a line while keeping weight and overall shackle length to a minimum. Ideal for halyards and sheets.
LB – Large Bails
Provide room for up to three additional shackles or a combination of shackles and lines. Ideal for spinnaker sheets, guys or other multi-line applications.
CB – Clevis Bails
Do not require splicing and provide moveable attachments to rings, deck fittings, furlers, rolling furlers, etc. Ideal for many uses.
