Description
This new version of Yale ULS Yacht Braid double-braid polyester made with a low angle braided core. Based on polyester fiber advances and this low angle construction, now maintains improved strengths and lower stretch. A firm, yet easily spliceable rope that allows for good handling.
Applications:Halyards and sheets
Construction:Core is Braided polyester. Sleeve is 24-strand, two end per carrier polyester.
| Diameter (Inches) | Weight (Lbs/100ft) | Average Spliced Break Strength* (Lbs) | Minimum Spliced Break Strength* (Lbs) | Maximum Work Load 5:1 (Lbs) |
| 1/4 | 1.8 | 2,500 | 2,250 | 500 |
| 5/16 | 2.9 | 3,290 | 2,961 | 658 |
| 3/8 | 4.2 | 5,800 | 5,220 | 1,160 |
| 7/16 | 5.7 | 7,260 | 6,534 | 1,452 |
| 1/2 | 8.0 | 9,700 | 8,730 | 1,940 |
| 9/16 | 10.4 | 11,870 | 10,683 | 2,374 |
| 5/8 | 12.7 | 14,500 | 13,050 | 2,900 |
| 3/4 | 16.2 | 17,800 | 16,020 |
3,560 |
